Strong Wall and Floor /
Our strong wall and floor enables testing of large size components and structures. Structures may be supported by either the strong wall itself or from a substantial steel frame built at a height of 3m above the strong floor.
| Strong wall dimensions | 3m (h) x 3.5m (w) |
| Strong floor dimensions | 16m (l) x 3.5m (w) |
| Strong wall channel layout | 6 x 3m channels at 0.5m centres |
| Strong floor channel layout | 6 x 3m channels at 0.5m centres |
| Channel strength per attachment point | Max 55kN (tensile) Max 70kN (shear) |
